A lightweight body means more payload . . . lower fuel costs.

Aluminum is strong, rigid and enduring . . . giving you many extra years of superb performance.


Standard Features
Length: 24" increments. Typically 8'-28;.
Width: 96" or 102" Outside Dimension.
Height: 78" or 84" or 90" or 96" Inside Dimension.
Recessed roofrails protect all marker lights.
One piece aluminum roofskin, perimeter riveted, sealed and held in tension by strong arched 2" top-hat type section aluminum roof bows on 25"  centres.
Satincoated, all steel welded, square shaped rear door frame.
.040 th. aluminum sheet body panels riveted on 3" centres.
1 1/2" th. Z-type wall post extrusions on 24" centres.

Structural steel channel longsills.
Hi-tensile 11 ga steel channel cross members on 6" centres bolted thru heavy duty rubrails with two (2) zinc plated bolts per crossmember.
1 1/8" th. laminated/varnished hardwood floor, shiplapped to fit properly. NO BUTT JOINTS.
1/4" th. "Good 1 side" plywood on sidewalls and front wall.
3" dock extension and ICC, Tee or step type rear bumper system.
Dual bulb marker lights, reflectors, dome lights, mud flaps.
Van body undercoated to suit

Options
Custom Length: as required
Custom Width: 90" Outside Dimension.
Custom Height: as required (min. 72" - max. 108")
White or silver rivets.
Stainless steel covered front cornerposts for a bright and shiny finish.
Stainless steel rear door frames.
Square front corner or aerodynamic styling.
Nosecones or Nosefairings.
Choice of exterior body panels; smooth or corrugated, prepainted white or custom paint.
Side doors located and sized according to your requirements, either in a roll up or swing style.
Choice of rear door configurations; roll up or 2, 3 or 4 panel swing doors (full or narrow opening).
Translucent roof or circular skylites.
Wheel wells for low mount bodies.
Wall posts on 12" centres.
Structural steel channel or I beam crossmembers on 12" centres (or as required).
1 1/8" th. hardwood floor (or thicker if required).
Steel or aluminum checkerplate "bathtub" style floors with/without drainholes.
Aluminum extruded "reefer" floor.
Cargo track/tiebar.
1/2" th. plywood lining.
Steel/hardwood or plastic scuffliners.
Front protective angle.
Galvanized steel or kemlite plastic lining.
8" dock extensions
Insulation: Fiberglass, styrofoam or "blown-in" Polyurethane foam.
Refrigeration units.
Heaters.
Numerous kinds of tuck-a-way or rail type liftgates.
Walkramps.
Back up alarms.
Highmounted tail-lights.
Midway turn signals.
Sealed marker lighting systems.
Undermount tool boxes.
Perimeter skirting.
