Standard Features
Length: 24" increments. Typically 8'-28;Width: 96" or 102" Outside Dimension.Height: 78" or 84" or 90" or 96" Inside Dimension.
Recessed roofrails protect all marker lights.
One piece aluminum roofskin, perimeter rivetted, sealed and held in tension by strong arched 1" galvanized roof bows on 24" centres.
Satincoated, all steel welded, square shaped reardoor frame. 5/8" plywood panel side walls with 18 oz.
"Gelcoat" woven roven fiberglass matting on each
side.
Dual bulb marker lights, reflectors, dome lights, mud flaps.
Van body undercoated to suit

Structural steel C channel longsills.
Structural steel C channel cross members on
12" centres bolted thru heavy duty rubrails with two (2) zinc plated bolts per crossmember.
1 1/8" th. laminated/varnished hardwood floor, shiplapped to fit properly. NO BUTT JOINTS.
3" dock extension and ICC, Tee or step type rear bumper system.


Fiberglass reinforced plywood side and front walls allow for greater interior width . . . more cargo space.


Options
Custom Legnth: as required
Custom Width: Typically 90" Outside Dimension.
Custom Height: as required (Typically min. 72" - max. 108")
Stainless steel rear door frames.
Square front corner or aerodynamic styling.
Nosecones or Nosefairings.
Custom painting.
Side doors located and sized according to your requirements, either in a roll up or swing style.
Choice of rear door configurations; roll up or 2, 3, or 4 panel swing doors (full or narrow opening).
Translucent roof or circular skylites.
Threshold plates or floor finishing angles.
Wheel wells for low mount bodies.
Wall posts on 12" centres.
Structural steel channel or I beam crossmembers on 12" centres (or as required).
1 1/8" th. hardwood floor (or thicker if required).
Steel or aluminum checkerplate "bathtub" style floors with/without drainholes.
Aluminum extruded "reefer" floor.
Cargo track/tiebar.
Plywood, galvanized steel, or kemlite lining if required.
Steel, hardwood, plastic or embedded scuffliners.
Front protective angle.
8" dock extensions
Insulation: Fiberglass, styrofoam or "blown-in" Polyurethane foam.
Refrigeration units.
Heaters.
Numerous kinds of tuck-a-way or rail type liftgates.
Walkramps.
Back up alarms.
High mounted tail-lights.
Sealed marker lighting systems.
Midway turn signals.
Perimeter skirting.
Undermount toolboxes.
